memperkenalkan
Nomor Produk:Si… T/K 5-50
Pasangan gesekan geser:SI… T/K Steel/PTFE Bahan Komposit
Fitur:Si ... t/k self - pelumas ujung batang rakitan terdiri dari ujung batang stainless steel dan self - pelumas bantalan polos bola radial (ge ... c). Ujung batang terbuat dari baja tahan karat dan tidak memerlukan pelumasan.
Kisaran Suhu Operasi: SI ... T/K -50 derajat ke +150 derajat
Industri aplikasi:
Mesin Konstruksi:
Ujung batang sambungan bola stainless steel untuk excavator, bantalan batang pengikat untuk loader
01
Peralatan Otomasi:
Ujung batang sambungan bola stainless stainless untuk robot
02
Industri otomotif:
Batang pengikat silinder kemudi, sendi heim 1.25mm untuk sistem suspensi
03
Mesin Tekstil:
Ujung batang clevis stainless steel untuk lengan ayun transmisi
04
|
Bantalan Nomor |
(Ukuran) |
Peringkat beban |
Berat |
||||||||||||||
|
d |
d3 6H |
B |
C1 |
W |
h1 |
d2 |
L4 |
L5 |
d4 |
d5 |
DK |
L3 Min |
a |
dyn.c |
STATC |
||
|
Si5t/k |
5 |
M5×0.8 |
8 |
6 |
9 |
27 |
18 |
36 |
4 |
8.5 |
11 |
11.11 |
10 |
13 |
5.70 |
6.00 |
16 |
|
Si6t/k |
6 |
M6×1.0 |
9 |
6.75 |
11 |
30 |
20 |
40 |
5 |
10 |
13 |
12.70 |
12 |
13 |
7.20 |
7.65 |
22 |
|
Si8t/k |
8 |
M8×1.25 |
12 |
9 |
14 |
36 |
24 |
48 |
5 |
12.5 |
16 |
15.8753 |
16 |
14 |
11.6 |
12.9 |
47 |
|
Si10t/k |
10 |
M10×1.5 |
14 |
10.5 |
17 |
43 |
28 |
57 |
6.5 |
15 |
19 |
19.05 |
20 |
13 |
14.5 |
18.0 |
77 |
|
Si10-1t/k |
10 |
M10x1.25 |
14 |
10.5 |
17 |
43 |
28 |
57 |
6.5 |
15 |
19 |
19.05 |
20 |
13 |
14.5 |
18.0 |
77 |
|
Si12t/k |
12 |
M12x1.75 |
16 |
12 |
19 |
50 |
32 |
66 |
6.5 |
17.5 |
22 |
22.225 |
22 |
13 |
17.0 |
24.0 |
100 |
|
Si12-1t/k |
12 |
M12x1.25 |
16 |
12 |
19 |
50 |
32 |
66 |
6.5 |
17.5 |
22 |
22.225 |
22 |
13 |
17.0 |
24.0 |
100 |
|
Si14t/k |
14 |
M14×2.0 |
19 |
13.5 |
22 |
57 |
36 |
75 |
8 |
20 |
25 |
25.40 |
25 |
16 |
24.0 |
31.0 |
160 |
|
Si14-1t/k |
14 |
M4x1.5 |
19 |
13.5 |
22 |
57 |
36 |
75 |
8 |
20 |
25 |
25.40 |
25 |
16 |
24.0 |
31.0 |
160 |
|
Si16t/k |
16 |
M16×2.0 |
21 |
15 |
24 |
64 |
40 |
84 |
8 |
22 |
27 |
28.575 |
28 |
15 |
28.5 |
39.0 |
220 |
|
Si16-1t/k |
16 |
M16×1.5 |
21 |
15 |
24 |
64 |
40 |
84 |
8 |
22 |
27 |
28.575 |
28 |
15 |
28.5 |
39.0 |
220 |
|
Si18t/k |
18 |
M18×1.5 |
23 |
16.5 |
27 |
71 |
44 |
93 |
10 |
25 |
31 |
31.75 |
32 |
15 |
42.5 |
47.5 |
320 |
|
Si20t/k |
20 |
M20x1.5 |
25 |
18 |
30 |
77 |
50 |
102 |
10 |
27.5 |
34 |
34.925 |
33 |
14 |
42.5 |
57.0 |
420 |
|
Si22t/k |
22 |
M22×1.5 |
28 |
20 |
32 |
84 |
54 |
111 |
12 |
30 |
38 |
38.10 |
37 |
15 |
57.0 |
68.0 |
540 |
|
Si25t/k |
25 |
M24×2.0 |
31 |
22 |
36 |
94 |
60 |
124 |
12 |
33.5 |
42 |
42.85 |
42 |
15 |
68.0 |
85.0 |
720 |
|
Si28t/k |
28 |
M27×2.0 |
35 |
24 |
41 |
103 |
66 |
136 |
14 |
37 |
46 |
47.60 |
51 |
15 |
86.0 |
107.0 |
820 |
|
Si30t/k |
30 |
M30x2.0 |
37 |
25 |
41 |
110 |
70 |
145 |
15 |
40 |
50 |
50.80 |
51 |
17 |
88.0 |
114.0 |
1100 |
|
Si30-1t/k |
30 |
M27×2.0 |
37 |
25 |
41 |
110 |
70 |
145 |
15 |
40 |
50 |
50.80 |
51 |
17 |
88.0 |
114.0 |
1100 |
|
Si35t/k |
35 |
M36×2.0 |
43 |
28 |
50 |
125 |
81 |
165.5 |
17 |
46 |
58 |
57.10 |
56 |
16 |
101 |
206 |
1600 |
|
Si40t/k |
40 |
M42x2.0 |
49 |
33 |
55 |
142 |
91 |
187.5 |
19 |
53 |
65 |
66.60 |
60 |
17 |
124 |
280 |
2400 |
|
Si50t/k |
50 |
M48×2.0 |
60 |
45 |
65 |
160 |
117 |
218.5 |
23 |
65 |
75 |
82.50 |
65 |
12 |
308 |
485 |
5000 |
